HTC/Quinco SR Series 2 Flute M-42 Cobalt Ball End Mills
Regular Length
XL-Reach
Series SR / SRXL
2 Flute M-42 Cobalt Ball End Mills
Regular and XL-Reach lengths
Select Uncoated or AlTiN in the coating selector; the displayed price changes with the coating option.
Reg Length
| Part No. | Cut Dia. | Cut Dec | LOC | Shank | Flutes | OAL | Length Type | Coating / Price / Qty / Order |
|---|---|---|---|---|---|---|---|---|
| HTC/Quinco SR-4M | 1/8 | 0.1250 | 3/8 | 3/8 | 2 | 2-5/16 | Reg | |
| HTC/Quinco SR-6M | 3/16 | 0.1875 | 7/16 | 3/8 | 2 | 2-5/16 | Reg | |
| HTC/Quinco SR-8M | 1/4 | 0.2500 | 1/2 | 3/8 | 2 | 2-5/16 | Reg | |
| HTC/Quinco SR-8XM | 1/4 | 0.2500 | 5/8 | 3/8 | 2 | 2-7/16 | Reg | |
| HTC/Quinco SR-10M | 5/16 | 0.3125 | 9/16 | 3/8 | 2 | 2-5/16 | Reg | |
| HTC/Quinco SR-10XM | 5/16 | 0.3125 | 3/4 | 3/8 | 2 | 2-1/2 | Reg | |
| HTC/Quinco SR-12M | 3/8 | 0.3750 | 9/16 | 3/8 | 2 | 2-5/16 | Reg | |
| HTC/Quinco SR-12XM | 3/8 | 0.3750 | 3/4 | 3/8 | 2 | 2-1/2 | Reg | |
| HTC/Quinco SR-16M | 1/2 | 0.5000 | 1 | 1/2 | 2 | 3 | Reg | |
| HTC/Quinco SR-20M | 5/8 | 0.6250 | 1-5/16 | 5/8 | 2 | 3-7/16 | Reg | |
| HTC/Quinco SR-24M | 3/4 | 0.7500 | 1-5/16 | 3/4 | 2 | 3-9/16 | Reg | |
| HTC/Quinco SR-24XM | 3/4 | 0.7500 | 1-5/8 | 3/4 | 2 | 3-7/8 | Reg | |
| HTC/Quinco SR-32M | 1 | 1.0000 | 1-5/8 | 1 | 2 | 4-1/8 | Reg | |
| HTC/Quinco SR-32XM | 1 | 1.0000 | 2-1/4 | 1 | 2 | 4-3/4 | Reg | |
| HTC/Quinco SR-40M | 1-1/4 | 1.2500 | 2-1/2 | 1-1/4 | 2 | 5 | Reg | |
| HTC/Quinco SR-48M | 1-1/2 | 1.5000 | 2-1/2 | 1-1/4 | 2 | 5 | Reg |
XL-Reach
| Part No. | Cut Dia. | Cut Dec | LOC | Shank | Flutes | OAL | Length Type | Coating / Price / Qty / Order |
|---|---|---|---|---|---|---|---|---|
| HTC/Quinco SRXL-8M | 1/4 | 0.2500 | 1/2 | 1/4 | 2 | 4 | XL-Reach | |
| HTC/Quinco SRXL-10XM | 5/16 | 0.3125 | 1/2 | 1/4 | 2 | 4 | XL-Reach | |
| HTC/Quinco SRXL-12M | 3/8 | 0.3750 | 3/4 | 3/8 | 2 | 5 | XL-Reach | |
| HTC/Quinco SRXL-14XM | 7/16 | 0.4375 | 3/4 | 3/8 | 2 | 5 | XL-Reach | |
| HTC/Quinco SRXL-16M | 1/2 | 0.5000 | 1 | 1/2 | 2 | 6 | XL-Reach | |
| HTC/Quinco SRXL-18XM | 9/16 | 0.5625 | 1 | 1/2 | 2 | 6 | XL-Reach | |
| HTC/Quinco SRXL-20M | 5/8 | 0.6250 | 1-1/4 | 5/8 | 2 | 7-1/8 | XL-Reach | |
| HTC/Quinco SRXL-24XM | 3/4 | 0.7500 | 1-1/4 | 5/8 | 2 | 7-1/8 | XL-Reach | |
| HTC/Quinco SRXL-24M | 3/4 | 0.7500 | 1-1/2 | 3/4 | 2 | 8-1/4 | XL-Reach | |
| HTC/Quinco SRXL-28XM | 7/8 | 0.8750 | 1-1/2 | 3/4 | 2 | 8-1/4 | XL-Reach | |
| HTC/Quinco SRXL-32M | 1 | 1.0000 | 2 | 1 | 2 | 10-1/4 | XL-Reach | |
| HTC/Quinco SRXL-36XM | 1-1/8 | 1.1250 | 2 | 1 | 2 | 10-1/4 | XL-Reach |
